High performance infrared dryers cure plastisol,
water-based and discharge inks at ultra-high rates |
|
|
BigRed V Series dryers are high performance machines offered in 30" and 54" belt widths, each with 3 or 4 heaters per chamber. 54" models with 4 heaters can cure over 950 shirts/hr* printed with plastisol ink, 475/hr* printed with water-based ink, and 112/hr* printed with digital white ink!
(See chart below for capacities of other models.)All BigRed dryers feature digital temperature control, air cooled skin with filtered intake, separate make up air system, powered negative air exhaust, and cooling tray at exit.
(See chart below for capacities of other models.)All BigRed dryers feature digital temperature control, air cooled skin with filtered intake, separate make up air system, powered negative air exhaust, and cooling tray at exit.
|
FAST
450 - 900+ plastisol shirts/hr* 175 - 400+ water based shirts/hr* SMART Unique cooling bed at exit, cools as garments exit the chamber. ACCURATE Temperature controller is accurate to +/-1 degree F. Digital PID with Fuzzy logic is the most advanced in the industry.CONVENIENT Digital belt speed voltmeter, a must have! VERSATILE Make-up Air and Negative Exhaust Air, removes moisture and fumes fast. |
FILTERED
Filtered air intake provides clean curing air, no recycled fumes! HEAVY DUTY "X-Series" Conveyor Belt Tracking System. BELT WIDTH (max garment width) 30" (76 cm) or 54" (137 cm) HEATER WIDTH 24" (61 cm) or 48" (122 cm) MAXIMUM IMAGE WIDTH 20" (51 cm) or 44" (112 cm) (Heater width minus 4" [10 cm])EXPANDABLE Add heat chambers and belt extensions. |
|
OPTIONS
|
|
*Production speeds are estimates and will vary depending on ink manufacturer, humidity of shop, and other variables.
